Wedge Wire Filter Element

What Is a Wedge Wire Filter Element



It is a precision-engineered cylindrical or flat filtering component manufactured from stainless steel V-shaped profile wires. The profile wires are resistance-welded onto a grid of support rods, creating a rigid structure with continuous, uniform slots. This all-welded construction gives the filter element high mechanical strength, enabling it to withstand differential pressure without deformation or failure. The element can be manufactured as a cylindrical tube, a flat panel, a curved DSM screen, or a basket, depending on the intended application and equipment configuration.

Precision Filtration and Anti-Clogging Performance



The wedge wire filter element delivers consistent filtration performance because the V-shaped slot geometry produces openings that are narrow on the outside and wider on the inside. Particles that enter the slot make contact at only two points with the wire edges, which prevents them from becoming wedged. This design characteristic is the main reason wedge wire elements resist blinding far better than woven wire mesh or perforated plates. When backwashing, the wider internal opening allows trapped solids to be flushed away easily. The result is a filter element that maintains its initial flow capacity over many cleaning cycles. Slot openings can be manufactured from 0.025 mm up to 3.0 mm, with common industrial filtration applications using 0.1 to 1.0 mm slots.

Material Selection for Corrosive Environments



The operating environment determines the appropriate material selection for the filter element. Stainless steel 304 and 316L are standard choices for most water and mild chemical applications. For more aggressive media, such as chloride-rich brine, acidic solutions, or high-temperature hydrocarbons, we offer higher-grade materials including 2205 duplex stainless steel, 904L, Hastelloy C276, and titanium. The material choice directly affects the service life of the filter element, particularly in applications where corrosion and erosion are factors.

Wedge wire filter elements are found in a broad range of industrial filtration processes. In the petrochemical industry, they are used as catalyst retention screens and for mother liquor filtration. In water treatment plants, they serve as resin traps and filter underdrains. In pharmaceutical manufacturing, they provide sterile filtration and product recovery. In food processing, they are used for juice clarification, beer filtration, and syrup polishing. They also serve in mining and mineral processing for ore slurry classification and in pulp and paper mills for fiber recovery.

Anping County Yan Zhao Mining Sieve Mesh Co., Ltd. has been manufacturing wedge wire products for over 20 years. Our facility operates more than 60 production units, including specialized wedge wire drawing lines and precision welding machines that allow us to maintain tight tolerances on slot openings. We operate under the ISO9001:2008 quality management system. Each filter element is custom manufactured to customer specifications. We support OEM/ODM services and can produce to technical drawings or customer-provided samples. For custom elements, we confirm material grade, slot opening, outer diameter, length, and end connection type before production begins. A sample can be provided for confirmation before mass production. Typical lead time for custom elements is 7 to 30 days depending on complexity.

We offer flexible ordering with no mandatory minimum quantity. Our payment terms for custom products are 50% deposit by T/T and 50% balance before shipment. We accept EXW, FOB, and DDP trade terms. Every element undergoes a 100% final inspection before packing. For international shipping, we use fumigation-free plywood boxes. Each element is sprayed with anti-rust oil and wrapped with foam padding. We accept third-party inspections for large orders and can provide inspection reports upon request.
